Outdoor Aluminum PVC Sports Tent
Guarantee: Frame 5years, fabric 3 years.
Wind loading: 80km/h.
Snow loading: 0.3 kn/sqm
Sports Size details
| tem | Size | Side high | ridge high | Bay distance |
| PT10 | 10m width,the length is unlimited | 3m | 5.0 | 5m |
| PT11 | 11m width,the length is unlimited | 3m | 5.2 | 5m |
| PT12 | 12m width,the length is unlimited | 3m | 5.3 | 5m |
| PT13 | 13m width,the length is unlimited | 3m | 5.4 | 5m |
| PT14 | 14m width,the length is unlimited | 3m | 5.5 | 5m |
| PT15 | 15m width,the length is unlimited | 3m | 5.5 | 5m |
| PT16 | 16m width,the length is unlimited | 3m | 5.6 | 5m |
| PT18 | 18m width,the length is unlimited | 3m | 5.7 | 5m |
| Structure of marquee: | |||||||
| Aluminum profile | high pressed extrued aluminum alloy 6061-T6,122X68X3mm for 10m,11m,12mwidth | ||||||
| 166x88x3mm for 13m, 14m. 15m, 17m, 18m width. All are anodized | |||||||
| Steel parts | hot-dipped galvanized , Passed 144 hour of salt spraying test | ||||||
| Raw material of marquee | |||||||
| Top roof fabric | 850g/sqm(24 Ounce) laminate Vinyl, waterproof , fire retardant M2 | ||||||
| UV protection, and Rotproof. Blackout | |||||||
| Side panels | (1) 650g/sqm(19 Ounce) laminate Vinyl, waterproof , fire retardant M2 | ||||||
| UV protection, and Rotproof. Translucence. | |||||||
| (2) 5cm thickness of sandwitch solid wall, ABS Solidwall,Glass wall | |||||||
| flame retardant,Heat resistant and Rotproof. | |||||||
Options accessories
What advantage:
| Item | Our manufactory | Some manufactories |
| Side height | 3m | lower 2.7m or 2.5m |
| Aluminum profile | Bigger 166x88x3mm | Smaller 122x68x2.5mm profile |
| Fabric | 850g/sqm, special treated | 750g/sqm or 650g/sqm, no special treated |
| Steel joints | Good welding, Spray salt resistant 144hour | Bad welding, Spray salt resistant about 80 hour |
| Assembly accuracy | Bolt and holes can fit exactly and fixed | Bolt is difficult to get through hole and fixed. |
| TransparencyPVC | UV Aging test, -20º C resistant | No UV Aging test, can' t be 20º Cresistant, breaken |
| Sidewallaccessories | Nylon rope+Nickel Eyelet | Zippper, easy breaken. or cotton rope, easy rot |
| Rachet | Bigger rachet+nylon 50mm ribbon | Small rachet+polyester ribbon, easy breaken |
| Cover lappetstructure | Aluminum rails+screw bolt | Elastic rope, easy breaken and water can' t flow. |
| Roof wire | 201# steel wire, stainlesss | Generally steel wire, easy stain |
| Support beam | " X" brace beam, galvanized steel | port beam, thin aluminum |
| Gable triangle wall | The middle is aluminum slots | The middle is velcro or rope. |
| Wind loading | Wind loading 80km/h test report | No Wind loading test report |
