Dia 6m Outdoor Polygon Hexagon Pagoda Tent With ABS Wall

  • LPOUTDOORS
  • 6306220090
  • 6m

Dia 6m Outdoor Polygon Hexagon Pagoda Tent With ABS Wall



Succeful  Case:

1. 2010 World Cup Tent Official Supplier

2. 2010 Commonwealth Game  Tent Official  supplier

3. Sports tent  for 2012 London Olympic game.

Dia 6m Outdoor Polygon Marquee Pagoda Tent with ABS Wall

Dia 6m Outdoor Polygon Marquee Pagoda Tent with ABS Wall

Guarantee
Frame 5years, fabric 3 years.

Wind loading: 100km/h.
Snow loading: 0.5kn/sqm

Certificate: Wind loading test, Vinyl Flame retardant M2, lining flame retardant BS5867
Galvanized Salt spray 144hours test, UV aging certificate, Aluminum 6061 test
Fabric RoHS certificate. Transparency PVC -20º C to 70º C resistant



Detailed specification:

(1)Size:

ItemWidth(m)Length(m)Side height(m)Bay space(m)
PT 3x3m332.43
PT 4x4m442.44
PT 5x5m552.75
PT 6x6m662.76
PT 8x8m882.84
PT 10x10m10102.85
PT 12x12m12123.06
PT 14x14m14143.07
PT 4x8m482.74
PT 5x10m5102.75
PT 6x12m6122.7
6

(2)Frame: Hard pressed extruded aluminum 6061/T6 anodized, hot DIP galvanized steel joints, and passed the 144hours of salt spraying test.


(3)Cover material: 850G/M2 vinyl blockout, white with blue stripe for top cover, 650G/M2 for sidewalls vinyl blockout, waterproof, UV protection, rotproof Flame retardant M2.

(4)Options: Transparency PVC windows, grass anchors, wood floor, lining and so on.
